LinqAF: The (possible) future

This is part of a series on LinqAF, you should start with the first post.

What’s missing from LinqAF?

The number one missing thing is performance.  LinqAF isn’t terribly slow, but it’s not consistently faster than LINQ-to-Objects and there’s no real reason it couldn’t be.  This would take the form of much more extensive profiling, and a likely a decent chunk of unsafe code.

There are also lots of additional operators that could be added.  Operators new to 4.7.1 like Append, Prepend, SkipLast, TakeLast, and ToHashSet or the extensive operators available in packages like MoreLINQ.  While the nature of LinqAF means each additional operator adds significantly to the generated code size, the code generation infrastructure makes it entirely feasible.

There are built-in enumerables that aren’t optimized for, like the Dictionary<TKey, TValue> and SortedDictionary<TKey, TValue> types, because they require more effort as a consequence of having two generic parameters.  It’d be neat to include the immutable collections introduced in .NET 4.5 as well.

What’s missing from C#?

cat-3068896_640

Missing from this blog?  On topic images.

A few changes to C# would make it possible to meaningfully improve LinqAF – ref extension methods, and improvements to generic type inferencing.

In the places where LinqAF does use extension methods (mostly in the numerical operators like Max, Average, and Sum), it’s forced to pass the source enumerable by value.  This entails making a copy of a (potentially quite large) struct, which has a deleterious impact on performance.  It is because of this copying cost that internally LinqAF passes all enumerables by reference.  Ref extension methods, allowing something like static MyEnumerable<TSource> MyOperator<TSource>(this ref TSource source), would prevent this copying.  This feature may make it into a future version of C#, and is presently championed by Mads Torgersen.

The reason LinqAF doesn’t use extension methods more extensively is because of weaknesses in C#’s generic type inferencing.  In a nutshell,

// in some static class
public static WhereEnumerable<TItem, TInnerEnumerable, TInnerEnumerator>
  Where<TItem, TInnerEnumerable, TInnerEnumerator>(
    this TInnerEnumerable source,
    Func<TItem, bool> predicate
  )
  where TInnerEnumerable: struct, IStructEnumerable<TItem, TInnerEnumerator>
  where TInnerEnumerator: struct, IStructEnumerator<TItem>
{ /* ... */ }

will not successfully be invoked by code like

var e = /* some struct implementing IStructEnumerable<...>
e.Where(i => true);

instead it fails with a CS0411 error (type arguments for the method cannot be inferred).  If this weren’t the case everything except the overrides in LinqAF could be implemented as extension methods, which would drastically reduce the size of the codebase and the final DLL.  The one attempt in this direction that I’m aware of came to nothing due to problems with backwards compatibility.  With compatibility concerns, the increase in complexity, and presumably compile times – I’d be a little surprised if it were done in a future C# version.  That said, LinqAF would benefit from it if it were.

What could be improved?

As mentioned in an earlier post, I’m very interested in alternatives to BoxedEnumerable<T>.  I spent a decent amount of time playing around with a tagged union approach, but could never come up with anything workable.

The RangeEnumerable<T> type being generic over T instead of being bound to int is a blemish.  Fixing this would let me remove the MiscUtil dependency, and would improve the performance of the Range operator. The major stumbling block is that the LinqAF.Generator project assumes all enumerables are generic over T, and Range being an exception would require significant amounts of work.

And that’s it!

This is the end of my series on LinqAF.  Once again, the code is on Github and a Nuget package is available.  Below is a table of contents for easy reference.

Thanks for reading!

Table of contents


LinqAF: Benchmarks

This is part of a series on LinqAF, you should start with the first post.

How is LinqAF benchmarked?

I make use of the excellent BenchmarkDotNet library which makes it easy to profile different configurations, and calculate meaningful statistics.  Concretely, I profile both the legacy x86 JIT and the x64 RyuJit configurations with the concurrent server garbage collector.

I created separate benchmarks for:

  • Each LINQ operator, including different overrides
  • Nullable and non-nullable versions for Average, Max, Min, and Sum
  • Both typed and untyped underlying enumerables for Cast
  • Sized and unsized underlying enumerables for Reverse, ToArray, ToDictionary, and ToList
  • Three actual LINQ uses from the Stack Overflow, Jil, and Roslyn codebases
  • One giant synthetic case that uses very nearly every operator at once

I ran all benchmarks on a machine with the following specs (as output by BenchmarkDotNet):

BenchmarkDotNet=v0.10.9, OS=Windows 10 Redstone 1 (10.0.14393)
Processor=Intel Core i7-6900K CPU 3.20GHz (Skylake), ProcessorCount=16

funny-2759296_640

Cats reacting to poor performance.

My goal with LinqAF was to produce a (very nearly) allocation free implementation of LINQ-to-Objects, and so that is what I focused on when benchmarking – either zero allocations when possible, or fewer allocations than the equivalent LINQ-to-Objects operator.  Ultimately, I did achieve my goal with LinqAF – however, since I didn’t focus on performance, there are plenty of cases where LINQ-to-Objects is faster than LinqAF.

In particular, the following operators are slower in LinqAF than in LINQ-to-Objects:

  • Any (without predicate)
  • Average
  • Cast (if the underlying type is actually an IEnumerable<T>)
  • Concat
  • DefaultIfEmpty (with a parameter)
  • Distinct
  • Except
  • GroupBy
  • GroupJoin
  • Intersect
  • Join
  • Max (for nullable types)
  • Min (for nullable types)
  • OrderBy & OrderByDescending
  • Range
  • Select
  • SelectMany
  • SequenceEqual
  • Skip & SkipWhile
  • Sum (for nullable types)
  • Take & TakeWhile
  • ThenBy & ThenByDescending
  • ToArray (if the underlying type isn’t an IList<T>)
  • ToDictionary
  • ToList
  • ToLookup
  • Union
  • Where
  • Zip

Most of these operations are only a little slower, but Cast is actually quite a bit slower (taking more than twice as much time).  This is because an optimization that is available to LINQ-to-Objects is made impossible by LinqAF’s “everything is a struct”-design.

You can run all the benchmarks on your own by executing the LinqAF.Benchmark project – be sure to build in Release mode, or you’ll get inaccurate results.  A full log of the run I did for this post can be found here – at the end of the file you’ll find all the slower benchmarks, and how much slower they were exactly.

Benchmarking is always fraught with issues – if you have any interesting cases where LinqAF allocates more than LINQ-to-Objects or is incredibly slower I’d be interested in hearing about it.

What’s next?

In the last post in this series, I’ll go over what’s missing for LinqAF as well as what direction future work could take.


LinqAF: Testing

This is part of a series on LinqAF, you should start with the first post.

How is LinqAF tested?

kittens-1534083_640

Cats testing claws.

In comparison to LINQ-to-Objects, LinqAF has a much larger surface to test – every enumerable implementation (of which there is at least one, and often more than one, per LINQ operation) exposes more than 3,000 methods.

Every operation has its own test class (using Microsoft’s UnitTestFramework), and includes at least the following tests:

  • Universal – which tests that every enumerable exposes the expected methods for the operation.  I.E. AnyTests.Universal confirms all enumerables have Any() and Any(Func<T, bool>) methods.
  • Malformed – which tests that every operation properly fails if called on a malformed (typically obtained via default(T)) enumerable.
  • Chaining – which tests that every operation performs as expected when called on each enumerable.

Most operation’s test class also has an Errors test, which assures that every enumerable properly handles the error cases (like null arguments) in a consistent and correct manner.

Each operation also has additional tests that cover simple invocations (typically on a single enumerable), for easy of debugging.

Finally, I pulled in the entire Edulinq test suite.  This covers all the little edge cases of a proper LINQ implementations, kudos to Jon Skeet yet again.

What’s the LinqAF.TestRunner project for?

Visual Studio’s test runner process falls over if you attempt to run the entire LinqAF test suite – a number of the tests create lots and lots of types, which eventually results in an OutOfMemoryException in the 32-bit process.

TestRunner runs every test in a separate process, in addition to gathering coverage statistics using OpenCover.  I use Visual Studio while bug fixing, and the TestRunner project when confirm that a build is ready for release.  I don’t use TestRunner during normal development because it takes between several hours and a day or so to run (depending on the machine I’m using).

What’s next?

In the next post, I’ll cover how I’ve benchmarked LinqAF as well the results of said benchmarking.


LinqAF: SelectMany and boxing

This is part of a series on LinqAF, you should start with the first post.

What’s weird about SelectMany?

kittens-555822_640

Selecting many cats.

Unlike most other LINQ operators, SelectMany is used with a delegate that returns another enumerable.  Because a delegate is involved arbitrary logic may be invoked, which means that the “type” of enumerable returned may not be constant.

For example, the following code is perfectly legal:

new [] { 0, 1 }.SelectMany(
  i => i % 2 == 0 ?
    new [] { "foo" } :
    System.Linq.Enumerable.Empty<string>()
)

This presents no problem for LINQ-to-Objects since both enumerables implement IEnumerable<T> and there’s a free (in that it doesn’t allocate) upcast, but for LinqAF no such thing exists.

There’s no allocation-free way to handle this case, we must “box” the enumerable returned in either path.  For this purpose I introduced a BoxedEnumerable<T> which every enumerable can be converted to with a Box() call (an explicit cast also exists for all LinqAF’s enumerables).  This does result in an allocation (the boxed enumerable must be placed on the heap).

This does require changing the above example to:

new [] { 0, 1 }.SelectMany(
  i => i % 2 == 0 ?
    new [] { "foo" }.Box() :
    LinqAF.Enumerable.Empty<string>().Box()
)

This represents the only intentional non-“type inference compatible” deviation from LINQ-to-Objects.  While SelectMany is the operator this deviation is most likely to occur with, any case where different operators are coalesced into a single expression can trigger it.

I consider the BoxedEnumerable<T> type a blemish on LinqAF but I was unable to come up with a workable alternative, so if you come up with one I’d be interested in hearing about it.

What’s next?

I’ll be going over how LinqAF is tested.


LinqAF: Allocating

This is part of a series on LinqAF, you should start with the first post.

When does LinqAF allocate?

The whole point of LinqAF is to be a low-allocation re-implementation of LINQ-to-Objects, so why does it allocate at all?

The answer is that there are a few operations that, logically, must allocate:

  • Distinct
    • Needs to track what has already been yielded
  • Except
    • Needs to track what cannot be yielded
  • GroupJoin
    • Needs to keep track of groups as it iterates over a sequence
  • Intersect
    • Needs to track what can be yielded
  • Join
    • Needs to keep track of items in the first sequence to join against the second
  • OrderBy(Descending) & ThenBy(Descending)
    • Needs to enumerate the whole sequence before it can begin sorting
  • Reverse
    • Needs to enumerate the whole sequence to find the last item before yielding
  • ToArray
    • Has to allocate the returned array
  • ToList
    • Has to allocate the returned list
  • ToLookup
    • Needs to build an internal dictionary to lookup groups by
  • ToDictionary
    • Has to allocate the returned dictionary
  • Union
    • Needs to track what has already been yielded

There are many cases (like passing known Empty enumerables) that can be optimized to not allocate, but in general these are unavoidable.

LinqAF allows for some application-specific optimizations by letting consumers register an alternative IAllocator which handles actual allocations.  For example, you could exploit the knowledge that no enumerables in a web app survive past a request and re-use allocated List<T>s.

IAllocator exposes the following methods:

  • GetArray<T>(int)
  • ResizeArray<T>(ref T[], int)
  • GetEmptyList<T>(int?)
  • GetPopulatedList<T>(IEnumerable<T>)
  • GetEmptyDictionary<TKey, TValue>(int?, IEqualityComparer<TKey>)
  • EnumerableBoxed<T>()
    • This is called for profiling purposes only

How does LinqAF minimize the size of necessary allocations?

animal-welfare-2343456_640

It’s possible to safely reduce the number of cats pictured.

In cases where allocations must be made LinqAF can still minimize allocations by using specialized types rather than the generic ones in the BCL.

CompactSet<T> is used by Intersect, Except, Union, and Distinct in place of HashSet<T>.  It stores all elements in a single array (which can be shared in some cases, reducing duplication) and optimizes the common case where a “bucket” has a single value to avoid allocating an array.  CompactSet<T> only supports adding elements, as that is the only method needed for LINQ operators.

LookupHashtable<TKey, TElement> is used by ToLookup (which itself backs Join, GroupBy, and GroupJoin) in place of Dictionary<TKey, TElement>.  It also stores all elements in a single array, and optimizes the common case where a “bucket” has a single value.  Unlike CompactSet<T>, LookupHashtable<TKey, TElement> can be enumerated in a stable order.

OrderBy(Descending) uses a StructStack<T> in place of a Stack<T> internally to keep track of subsets needing sorting.  StructStack<T> only supports Push(T) and Pop(), as that’s all that is needed for OrderBy(Descending).

LinqAF also reduces allocation sizes by shrinking structs by omitting as many fields as possible, and by liberally applying [StructLayout(LayoutKind.Auto)] to allow the runtime to reorder fields for packing efficiency.

When does LINQ inherently allocate?

There are cases where the LINQ expression-to-method-calls transformation introduces some inherent allocations.  For example, repeat chains of from expressions like

int[] xs, ys, zs =/* initialization code */

var e =
  from x in xs
  from y in ys
  from z in zs
  select x + y + z;

introduces an anonymous object to hold x, y, and z.  The compiler produces code equivalent to

int[] xs, ys, zs =/* initialization code */

var e =
  xs.SelectMany(_ => ys, (x, y) => new { x, y })
    .SelectMany(_ => zs, (xy, z) => xy.x + xy.y + z);

which has an allocates four delegates, one of which itself allocates an anonymous object per invocation.

I personally always use explicit method calls rather than the expression-style of LINQ which makes any “inherent” allocations an explicit and visible part of my code.  If you prefer the expression-style, then you should be aware that there are cases where the compiler will insert allocations outside of LinqAF’s code.

What’s next?

I’ll cover the peculiar case of SelectMany and why LinqAF must have a notion of “boxing”.


LinqAF: All the operations

This is part of a series on LinqAF, you should start with the first post.

What operations does LinqAF support?

baby-cats-955895_640

So many operations.  And cats.

All the ones the LINQ does, and LinqAF sports numerous optimizations that additional type information makes possible.

Concretely:

There are also three static methods on Enumerable that expose special enumerables which sport many optimizations.  They are:

  • Empty
    • Aggregate() with no seed always throws
    • Aggregate() always returns seed, or seed passed to resultSelector, depending on overload
    • Any() is always false
    • AsEnumerable() always results in an empty IEnumerable
    • Average() over non-nullable types always throws an exception
    • Average() overnullable types always returns null
    • DefaultIfEmpty() can be optimized into a “OneItem” enumerable
    • Cast() always results in an empty enumerable of the destination type
    • Concat() calls return the non-empty parameter
    • Contains() always returns false
    • Count() is always 0
    • Distinct() always returns an empty enumerable
    • ElementAt() always throws an exception
    • ElementAtOrDefault() always returns default
    • First() always throws an exception
    • FirstOrDefault() always returns default
    • GroupJoin() results in an empty enumerable
    • Join() results in an empty enumerable
    • Last() always throws an exception
    • LastOrDefault() always returns default
    • LongCount() is always 0
    • Min() and Max() over non-nullable types always throw exceptions
    • Min() and Max() over nullable types always return null
    • OfType() always results in an empty enumerable of the destination type
    • OrderBy() and OrderByDescending() result in a special EmptyOrdered enumerable
    • Reverse() results in an empty enumerable
    • Select() results in an empty enumerable
    • SelectMany() results in an empty enumerable
    • SequenceEqual() always has the same result for many types (DefaultIfEmpty => false, another Empty => true)
    • SequenceEqual() devolves to a Count or Length check on things like List<T> or Dictionary<T,V>
    • Single() always throws an exception
    • SingleOrDefault() always returns default
    • Skip() and SkipWhile() result in an empty enumerable
    • Sum() is always 0
    • Take() and TakeWhile() result in an empty enumerable
    • ToArray(), ToList(), and ToDictionary() results can all be pre-sized to 0
    • ToLookup() can return a global, known empty, Lookup
    • Where() results in an empty enumerable
    • Zip() results in an empty enumerable
  • Range
    • Any() without a predicate just check the inner count
    • Count() and LongCount() just return the inner count
    • Distinct() with no comparer returns itself
    • ElementAt() and ElementAtOrDefault() are simple math ops
    • Contains() is a range check
    • First() and FirstOrDefault() return the starting element, if count > 0
    • Last() and LastOrDefault() are simple math ops
    • Max() is equivalent to Last()
    • Min() is equivalent to First()
    • Reverse() can return be optimized into a “ReverseRange” enumerable
    • SequenceEqual() against another range enumerable can just compare start and count
    • SequenceEqual() against a repeat enumerable is only true if count is 0 or 1
    • Single() and SingleOrDefault() just check against count and return start
    • Skip() advances start and reduces count
    • Take() reduces count
    • ToArray(), ToDictionary(), and ToList() can be pre-sized appropriately
  • Repeat
    • Any() without a predicate just check the inner count
    • Contains() just check against the inner object
    • Count() and LongCount() just return the inner count
    • Distinct() without a comparer returns a repeat enumerable with 0 or 1 items as appropriate
    • ElementAt() and ElementAtOrDefault() return the inner item
    • First() and FirstOrDefault() return the inner item
    • Last() and LastOrDefault() return the inner item
    • Max() and Min() return the inner item
    • SequenceEqual() against an empty enumerable is just a check against the inner count
    • SequenceEqual() against a range enumerable is only true if count is 0 or 1
    • SequenceEqual() against another repeat enumerable just checks for equality between the inner item and the inner count
    • Single() and SingleOrDefault() just check the inner count and return the inner item
    • Skip() is equivalent to reducing the inner count
    • Take() is equivalent to replacing the inner count
    • ToList() and ToArray() can be pre-sized appropriately

As mentioned in the above lists, LinqAF introduces a few new “kinds” of enumerables as optimizations.  Some of these actually exist behind the scenes in LINQ-to-Objects, but the IEnumerable<T> interface conceals that.  These new enumerables are:

  • EmptyOrdered
    • Representing an empty sequence that has been ordered
    • All the optimizations on Empty apply, except that Concat() calls with EmptyOrdered as a parameter cannot return EmptyOrdered – they return Empty if they would otherwise return EmptyOrdered
  • OneItemDefault
    • Represents a sequence that is known to only yield one value, and that value is default(T)
    • All() only checks against the single item
    • Any() without a predicate is always true
    • Contains() checks against the single item
    • Count() and LongCount() are always 1
    • Count() and LongCount() with predicates are 0 or 1, depending on the single item
    • DefaultIfEmpty() returns itself
    • ElementAt() throws if index is not 0, and always returns default(T) if it is
    • ElementAtOrDefault() always returns default(T)
    • First(), FirstOrDefault(), Last(), LastOrDefault(), Single(), and SingleOrDefault() all return default(T)
    • Reverse() returns itself
    • ToArray(), ToList(), and ToDictionary() can a be pre-sized to 1 item
    • OrderBy() and OrderByDescending() result in a special OneItemDefaultOrdered enumerable
  • OneItemSpecific
    • Represents a sequence that is known to only yield one value, but that value is determined at runtime
    • Has all the same optimizations as OneItemDefault, except the specified value is returned where appropriate and OrderBy() and OrderByDescending() result in a special OneItemSpecificOrdered enumerable
  • OneItem(Default|Specific)Ordered
    • Represents one of the OneItem enumerables that have been ordered
    • All the optimization on their paired OneItem enumerable apply, except that Concat() calls cannot return a OneItem(Default|Specific)Ordered – they return the paired unordered enumerable if they otherwise would
  • ReverseRange
    • Represents a Range that has been reversed – that is, it counts down from a value
    • All the optimizations on Range apply, except that calling Reverse() on a  ReverseRange results in a Range
  • SelectSelect
    • Represents repeated calls to Select() – this allows a single enumerator to handle the entire chain of calls
    • Select() results in yet another SelectSelect
    • Where() results in a SelectWhere
  • SelectWhere
    • Represents any number of  Select() calls followed by any number of Where() calls – this allows a single enumerator to handle the entire chain of calls
    • Where() results in a SelectWhere
  • WhereSelect
    • Represents any number of Where() calls followed by any number of Select() calls – this allows a single enumerator to handle the entire chain of calls
    • Select() results in a WhereSelect
  • WhereWhere
    • Represents repeated calls to Where() – this allows a single enumerator to handle the entire chain of calls
    • Select() results in a WhereSelect
    • Where() results in a WhereWhere

These gigantic lists are a pretty good demonstration of how many cases additional compile time typing lets us optimizes.

What’s next?

I’ll cover when LinqAF does allocate, why it does, and how you can provide your own allocator scheme to minimize the impact of those allocations.


LinqAF: Generating way too much code

This is part of a series on LinqAF, you should start with the first post.

Why use codegen for LinqAF?

As mentioned in the previous article, LinqAF defines a type per operator and has to define many instance methods on each type.  When you add it all up, replacing LINQ-to-Objects requires ~50 enumerable structs each of which exposes ~1,300 methods.

So yeah, I didn’t do it by hand.

The C# compiler has been re-implemented and open-sourced, resulting in the Roslyn project.  This makes it really easy to manipulate and reason about C# code, which I used to fashion a templating system to generate LinqAF.  Specifically, I was able to keep the templates mostly “correct” C# that benefited from type checking and Visual Studios navigation faculties.

Concretely:

  • Every LINQ operator has an interface defined (IConcat, IMin, ISelectMany, etc.)
  • Each logically distinct method gets a CommonImplementation… implementation (So Concat gets a few methods, Min gets a lot, SelectMany gets several)
  • A template is defined that implements the interfaces and calls the appropriate CommonImplementation methods.
    • Here dynamic comes into play, as many templates elide generic parameters (these parameters are filled in later)
  • Similarly templates are defined for various extension methods
    • Inter-operating with IEnumerable<T> and other collections defined in the BCL
    • Average
    • Concat for enumerables with two generic parameters
    • Except for enumerables with two generic parameters
    • Intersect for enumerables with two generic parameters
    • Max
    • Min
    • SequenceEqual for enumerables with two generic parameters
    • Sum
    • Union for enumerables with two generic parameters
  • Overrides that replace particular generated methods with other, static, C# code
    • This allows LinqAF to leverage static type information to avoid doing pointless work
    • For example, almost all operators on the EmptyEnumerable are replaced with implementations that elide most work
  • A separate project, LinqAF.Generator, processes all these templates to generate the final code

This code generation approach let me keep the “actual” implementation of LinqAF under 20,000 lines of code.

What are the downsides to code generation?

cat-3069979_640

Code generation is typically a worse idea than a cat

The biggest one is that iteration time is much worse, and it got worse as more operators were implemented.  This is mitigated somewhat by sharing common implementations in (…) CommonImplementation, allowing bug fixes to be copy/pasted for quick testing; bugs in the code generation parts are still slow to fix.

While limited in scope, the reliance on dynamic in certain places also means that the LinqAF project can compile even if there are actually type errors.  This was most common when adding new operators, and commenting out the other operators let me decrease the iteration time considerably.

Code generation is also harder to understand and setup as this post’s existence demonstrates.  Thankfully the Roslyn project, and it’s availability on Nuget, makes code generation considerably less difficult – using something like T4 or outright concatenation would have been even worse.

What’s next?

In what will probably be the longest post in the series, I cover most of the operators and the various optimizations that LinqAF has for them.
